11
Child Requirements
Rear-Facing Mode
OPTIONAL: To ensure a better t for
smaller infants, the Body Pillow (pg. 45)
and/or Head Pillow (pg. 48) may be used
in REAR-FACING mode ONLY.
Chest Clip at armpit level
Shoulder straps
must be at or just
below child’s
shoulders.
Top of head
MUST be 2.5
cm (1 in) or
more below top
of headrest or
shell.
Always use tether strap in rear facing harness installation.
Ball must be completely in
proper zone for child size:
Vehicle MUST be on
level ground.
LEVEL INDICATOR
REAR-FACING ONLY
1.8 - 18 kg (4 - 40 lbs)
44 - 101 cm (17 - 40 in)
REAR-FACING
Rear Facing
9 - 18 kg (20 - 40 lbs)
Rear Facing
1.9 - 9 kg (4 - 20 lbs)
For REAR-FACING installation, Recline
Ball should be in correct zone for child
size:
• White Zone: 1.8 - 9 kg (4 - 20 lbs)
• Black Zone: 9 - 22.6 kg (20 - 50 lbs)
