Removing and Installing the Seat Shell from the Base
Removing the Seat Shell from the Base
DO NOT install or use Seat Shell in vehicle without the Base. DO NOT use the
Base in the vehicle without the Seat Shell.
!
WARNING! DEATH or SERIOUS INJURY can occur.
To remove the Seat Shell from the Base:
1. Locate the red arrow on the Buckle
Storage Pouch or the white arrow
on the front of the Seat Shell.
NOTE: You may need to unroll the
Buckle Storage Pouch to locate the
red arrow.
2. Lift up on one of the two Rotation
Levers at either side of the Headrest
and rotate the Seat Shell until the
arrow on the Seat Shell aligns with
one of the white arrows on the Base.
3. Remove Seat Shell from Base.
