81
LATCH/UAS (Rear-Facing and Forward-Facing)
Installing LATCH/UAS
6. Squeeze handle on LockStrong
belt tensioner until lock indicator
turns RED, then lift up on belt
tensioner to allow access to the
belt path.
7. Attach LATCH/UAS Connectors
to vehicle Lower Anchor Bars.
Connectors will make an audible
CLICK when attached. Make sure
they are attached by pulling rmly
on connectors. If equipped with
Mini-Latch, DO NOT pull on red
Release Strap.
CLICK!
To Next Page
