Evenflo SIBBY - Securing the Child with 5-Point Harness; Adjusting Harness Strap Height

7
Note: Verify the stroller is locked in the open position by lifting up the
rear of the stroller using the parent’s handle.
Lock the rear brakes and remove the bumper bar (page 4).
5-point Harness:
The harness shoulder straps
G
must start at shoulder height or lower,
as shown, and use the harness strap loops
H
closest to the baby’s
shoulders. To adjust the height of the harness shoulder straps to the
baby’s shoulder height, do the following:
1. Remove each harness shoulder strap
G
from each buckle
L
, as
shown.
2. Thread each harness shoulder strap
G
under the harness strap loop
H
that is closest to the baby’s shoulder.
3. Reattach each harness shoulder strap
G
to each buckle
L
.
Place the baby in the seat and bring the crotch panel
I
up between
the child’s legs. Fasten each buckle
J
. For a snug, comfortable fit:
pull the shoulder straps
G
to tighten the shoulder restraint and pull
the waist restraint straps
K
to tighten the waist restraint.
Note:
To loosen the waist straps
K
, push in the release button
L
on the buckle
and pull.
To loosen shoulder straps push up on the retainer
M
while pulling down
on the shoulder strap.
Once the child is properly restrained, re-attach the bumper bar. Make
sure the bumper bar locks into position with audible clicks. Pull on the
bumper bar to make sure it is locked into place.
5-pt Harness
7
I
H
K
G
H
K
G
J
L
G
G
KK
To unlock harness, push button on
the crotch buckle then slide the
shoulder straps off the waist buckle.
CLICK!
The shoulder straps of the 5-point harness have 3 attachment
positions. Select the position that places the shoulder strap level with,
or below the top of the child’s shoulders.
High
Middle
Low
G
G
KK
G
G
KK
H
I
I
K
M
L
WARNING
To avoid serious injury from falling or sliding out, ALWAYS use
waist restraint.
