Rear-facing
Rear-facing Installation with
Lower Anchor Connectors (cont.)
Rear-facing Installation with
Lower Anchor Connectors (cont.)
Make sure the harness
straps are in one of the
four lower harness slots.
The harness straps MUST
start at shoulder height
or lower, using the strap
slots closest to your child’s
shoulders, as shown.
Attach the harness straps to
the splitter plate using the
infant position (p. 43) on
the harness straps.
As your child grows, you can
attach the harness straps to
the splitter plate using the
pockets at the end of the
straps.
2
IMPORTANT: Make sure both harness straps are
installed completely on the splitter plate, as shown.
3
DO NOT use the two upper set of harness slots
rear-facing. The harness may not properly restrain the
child during a crash.
WARNING
4
Pull the seat pad off of the
front of the child restraint.
Route the Lower Anchor
Connector strap and hook
through the
rear-facing belt paths.
IMPORTANT: Make sure
the Lower Anchor Connector
strap is in front of the crotch
strap, and it lies flat without
twisting, as shown. Reconnect
the seat pad to the front of the
child restraint.
