Evenflo SureRide - Visual Glossary of Components

13
12
Harness Adjuster
Strap
Crotch Strap
Buckle
Harness
Release Button
Seat Pad
Harness
Straps
Chest Clip
Top 2 Harness
Positions for
Forward-facing
ONLY
Bottom 3
Harness Positions
for Rear-facing
ONLY
Your vehicle components may be significantly different than
pictured. Consult your owner’s manual to help you identify
your vehicle components.
Back Seat
Belt Buckles
Center Lap
Belt
Tether Anchors
Forward-facing
ONLY
Back Seat
Retractor
Seat Crease
Lap/Shoulder
Belt
Lower
Vehicle
Anchor
Bars
Fold-down Armrest
Consult your vehicle’s owners manual.
Visual Glossary
Front View
IMPORTANT: If your vehicle has side air bags, please refer to
the warnings on page 3.
Note: Recline Stand
is nested below child
restraint.
Splitter Plate
Harness Straps
Tether Strap
and Hook
Instruction
Storage Area
Top 2 Harness
Positions for
Forward-facing
ONLY
Bottom 3
Harness Positions
for Rear-facing
ONLY
120
4
A I R B A G
20
30
10
Front Seat Lap and Shoulder Belts
Front Seat Retractor
Headrests
Must be in the lowest
position where the child
restraint is located.
Back View
Lower Anchor
Connector Assembly
Lower Anchor Connector
Assembly
Consult your vehicle
owner’s manual to determine
proper placement of child restraint
in your vehicle and familiarize
yourself with your vehicle’s
components.
Important
Visual Glossary
For U.S.
Customers:
This set of harness
slots can be for
either
forward-facing or
rear-facing use.
For Canadian
Customers:
This set of harness
slots can ONLY
be used
forward-facing.
For U.S.
Customers:
This set of harness
slots can be for
either
forward-facing or
rear-facing use.
For Canadian
Customers:
This set of harness
slots can ONLY
be used
forward-facing.
