SET 4 (ST-4)
SET 4 has five sublevels :
Bias : Correction Offset of the temperature
Unidad : Possibility to work in ºC or ºF
Out L : Limit percentage heaters power.
Sp.ll : Minimum set point process temperature
Sp.hl : Maximum set point process temperature.In water machines the
Value is 95 while in oil machines is 200.
SET 5 (ST-5)
DEF: Default to preset factory settings. Set to 100 to revert all SET
parameters back to factory settings.
SET 6 (ST-6)
LEVF locking function
Value 0: Denies access to all levels
Value 1: Allows access to all levels
SET 7 (ST-7)
COMS Communications interface activation On / Off
Addr Address assigned to the circuit
bAud Transmission speed 0-1-2 0 = 2400, 1 = 4800, 2 = 9600
PAr Parity bit 0-1-2
dEn TCU unit working with interface 4-20m Amp
must put value “1” If customer work with one TCU unit but if
costumer works with several TCU units all TCU units must be set
with value “0” less the last one it must be set with value “1”
TCU unit working with interface RS 485
must put value “1” in all TCU units.
