6
Installation (continued)
5
Marking the bracket positions
Mark “X” from the bottom of the mark. Align the top of the
bracket (A) with the mark, 1/16 in. from the front of the cabinet.
6
Installing the brackets into the cabinet and drawers
Make sure each bracket (A) is level and secure inside the cabinet with screws (C). Insert the drawer into the cabinet and close.
The release lever (1) will lock.
1/16"
(1.6 mm)
C
1
A
