FOR BEST PERFORMANCE, PLEASE BE SURE TO DO
THE FOL LOW ING BEFORE USING THIS TOOL
• Tightentheguntothecupsecurelywiththenutandfittingsupplied.
• Besuretohavetheproperairpressureattheguntooperate.Properairpressureforthistoolshouldnotexceed50PSI.
• Adjustfluidcontrolscrewandspraywidthadjustmentscrewtoyourdesiredpatternbeforeusingonproduction.
• Cleanallpartsafteruse.
In normal use, the nozzle wings are
horizontal as shown here. This provides a
vertical fan-shaped pattern which gives
maximum,evenmaterialcoverageasthegun
ismovedbackandforthparalleltothesurface
beingfinished.
Spraypatternmaybeinfinitelyadjusted
from round to flat.
Set inlet pressure at no more than 50 PSI. For optimum
performance, some materials may spray better at PSI
ratings below 50 PSI. If unsure, always test at PSI ratings before
usingonfinalproduction.Tryspray.Ifitistoofine,decreasetheair
pressureoropenfluidcontrolscrew.Ifthesprayistoothick,close
the fluid control screw. Regulate the pattern width and repeat
adjustmentofsprayasneeded.
®
®
®
AdjusTmENTs
sprAyiNg
Spraywidthadjustmentscrew
Turnrightforround,leftforfan.
Trigger pivot
Fluidcontrolscrew
Turnrighttodecreaseflow,
left to increase.
Air valve
Fluidneedlepackingandnut
