776-3758 5 Rev. 07/21/14
FOR BEST PERFORMANCE, PLEASE BE SURE TO DO
THE FOL LOW ING BEFORE USING THIS SPRAY GUN
• Tightentheguntothecupsecurelywiththenutandfittingsupplied.
• Besuretohavetheproperairpressureattheguntooperate.Properairpressureforthistoolshouldnotexceed36psigforlacquer
and 43 psig for enamel.
• Adjustfluidcontrolscrewandspraywidthadjustmentscrewtoyourdesiredpatternbeforeusingonproduction.
• Cleanallpartsafteruse.
Innormaluse,thenozzlewingsare
horizontalasshownhere.Thisprovides
averticalfan-shapedpatternwhichgives
maximum,evenmaterialcoverageasthe
gunismovedbackandforthparalleltothe
surfacebeingfinished.
Spraypatternmaybeinfinitelyadjusted
from round to flat.
Setinletpressureatnomorethan43psig.Foroptimum
performance,somematerialsmayspraybetteratpsig
ratingsbelow43psig.Ifunsure,alwaystestatpsigratings
beforeusingonfinalproduction.Tryspray.Ifitistoofine,
decreasetheairpressureoropenfluidcontrolscrew.Ifthe
sprayistoothick,closethefluidcontrolscrew.Regulatethe
patternwidthandrepeatadjustmentofsprayasneeded.
®
®
®
AdjusTmENTs
sprAyiNg
HVLP SPRAY GUN
Themodelyouhavepurchasedisaprofessional
highvolume,lowpressurespraygun.Itisdesigned
tosprayveryefcientlywithvirtuallynooverspray.
Toaccomplishthis,theinletpressureregulation
iscritical.Pleasebesuretoreadpressure
requirementcarefully.
Fluid control screw
Turnrighttodecreaseflow,
left to increase.
Air pressure regulator
Turnrighttodecreaseairpressure,
left to increase.
Spray width adjustment screw
Turnrightforround,leftforfan.
Air flow adjustment screw
Turnrighttodecreaseflow,
left to increase.
