APPLIANCE DETAILS
ELECTRICAL DETAILS:
Rated Voltage: 230 Vac 50 Hz
Supply Connection: 30 A (double pole switched fused outlet with 3mm contact gap)
Max Rated Inputs: 7.00 kW
Mains Supply Lead: 3 core x 2.5 mm² (not supplied)
This information can be found on the rating plate (data label) affixed to the underside of the appliance
PRODUCT SPECIFICATIONS:
2 x 2.00 kW thermostatic plates (diameter 180 mm)
2 x 1.50 kW thermostatic plates (diameter 145 mm)
Side control operation
COOKTOP SURFACE LAYOUT:
COOKTOP SIZES:
Relevant Sizes: LENGTH (mm) WIDTH (mm) HEIGHT (mm)
Cooker size 580 500 40 (85 incl. knobs)
Cut-out size 555 473 -
3
