INSTALLATION GUIDE
AP300
INSTALLING AP300
This section provides information and procedures required to install the AP300 Wireless Access
Point using various methods.
AP300 Installation Using Mounting Bracket
Figure 3 on the next page shows how to mount the AP300 access point to a wall or ceiling, First,
if applicable, position the mounting plate in the desired location on the wall or ceiling so the network
cable aligns with one of the larger opening in the mounting plat.
The AP300 Wireless Access Point installation must be performed by
certified technicians only and in compliance with all local/state/federal safety
requirements and building codes.
Proper grounding and surge protectors may be required in outdoor
The network coverage depends on the location and position of the AP300
Wireless Access Point.
Install the mounting plate with clips facing away from the wall or celling.
If mounting the AP300 on a wall, please insure that the orientation of the
bracket is correct so the Text on the AP300 is readable.
