Chapter 6 Verification
6.1 Verification basis
GB/T 17626.2 Electromagnetic compatibility(EMC) - Testing and
measurement techniques - ESD immunity test
IEC 61000-4-2 Electromagnetic compatibility (EMC)-Testing and
measurement techniques – Electrostatic discharge
immunity test
ISO 10605 Road vehicles — Test methods for electrical
disturbances from electrostatic discharge
6.2 Verification conditions
1. Temperature: 23
℃
2
℃
;
2. Relative humidity: 25%
～
45%R.H.;
3. Frequency: 50Hz±1Hz
或
60Hz±1Hz;
4. Atmospheric pressure: 86kPa~106kPa;
5. No electromagnetic environment will interfere with the test results.
6.3 Verification of ESD high voltage output
6.3.1 Instruments for the verification
High-voltage meter: the voltage range is 0~40kV, the resistance is 100GΩ and the
voltage accuracy is ±1%.
6.3.2 Verification items
Connection of the instrument and verification of the ESD output voltage should be
carried out as Fig.6.1.
