PF9800SeriesUser'sManual
Copyright © EVERFINE,Copyorspreadwithoutauthorizationisprohibited.
14
2
bindingpostofcurrent
input
± terminalisblackandAterminalisred.
3 Communicationinterface
PF9810/pf9811:StandardConfiguration:RS-232,
Optional:RS-485 、LAN
PF9804:Thisportisnotacommunicationinterface
4 Groundterminal
To ensure safety, please make sure that the
instrumentisreliablegroundinginuse.
5 Powersupplysocket
Inputinterfaceofinstrumentpower,including0.5A
fuse
