Chapter6SoftwareInstruction(PF9810/PF9811)
6.1Systemrequirements
(1)TheoperationsystemmustbeWindowsXPorWin7(ChineseorEnglish);
(2)Morethan2Mdisspace.
(3)Thedisplayresolutionis800×600orabove.800×600isadvised.
(4)OneserialportofRS-232.
6.2Softwareinstallation
Pleaseinsertsthediskettelabeled
‘
EVERFINE’intofloppydrive,GO
intothelatestChineseversionofPF9810/PF9811inthediskette,andrun
SETUP.EXE,thatis,itisgoingintotheinstallationprocess.The
installationcanbefinishedaccordingtotheprompts.
Aftertheinstallationiscompleted,thefileisplacedonthetargetpath
C:\EVERFINE\PF981X_X.XX.
6.3SoftwareUse
ThePCapplicationsoftwareofPF981Xisusedtoobtainthemeasured
valueandthedataofharmonicwave,whichistransmittedtothePC
throughtheinterfaceofRS-232.ThesedataaredisplayedonPCand
storedinPC.
OpenthePF981Xsoftwaretoshowthelogininterface,asfigure6.1
shown.
Functionmodulesofsoftwareinterfaceareasfollows:
(1)Menu:New,Open,Saveas,Print,Setcommunicationport,Transferdata,Set
totalharmoniccalculationmethod,Switchthesoftwareinterfaceversionof
ChineseandEnglishandsoon.
(2)Shortcuticon:New,Open,Saveas,Transferdata,Showthewindowandsoon.
(3)Mainwindowdisplay:normalmeasurementdisplayarea,Signalwaveform
displayarea,Harmonicfrequencyspectrdisplayarea,asshowninFigure6.1.
