Chapter5MeasurementFunction
5.1Displaywindow
Thereare4displaywindowsinthisinstrument:A,B,CandD,whichcandisplay
differentmeasurementresultssimultaneously.Thecontentofdisplaywindowcanbe
selectedbythecorrespondingFUNCTIONkeyonthewindowD.
Table5.1ThedisplaycontentofPF9804
Window DisplayContent MeasurementRange
A V U:3.0V~600V
I:0.005A~20A
P:1W~12.00kW
PF:-1.000~+1.000
Hz:45Hz~65Hz
B A
C (k)W
D PF,Hz
Table5.2ThedisplaycontentofPF9810/PF9811
Window DisplayContent MeasurementRange
A V U:3.0V~600V
I:0.005A~20A(PF9811)
0.5mA~2000mA(PF9810)
P:1W~12.00kW
PF:-1.000~+1.000
Hz:45Hz~65Hz
B A(PF9811)
mA(PF9810)
C (k)W(PF9811)
W(PF9810)
D PF,Hzor.**/tHd
WhenthePF9811andPF9810areusedtonormalmeasurement,thedisplayswhich
thefunctionkeystoswitchthewindowareshowninFigure5.1.
Figure5.1theloopswitchingdisplaycontentofnormalmeasurementbyPF9811/PF9810
