Specifications
Model ECMD100i
Imaging Device
1/3” Sony Super HAD
Ⅱ
Color CCD
Effective Picture Elements NTSC: 768(H) x 494(V) PAL: 752(H) x 582(V)
Horizontal Resolution
Color : 600TV lines
B/W : 700 TV Lines
Scanning System 2:1 Interlace
S/N Ratio More than 50dB
IR LEDs 24 LEDs with wavelength of 940nm
IR Range 32 feet or more (depends on scene and subject IR reflectivity)
Minimum illumination
0.1 Lux – at F1.4
0.000 Lux (IR ON)
Digital Noise Reduction 2D DNR On
Digital Wide Dynamic Range DWDR On
Power Source 12VDC ±10%
Power Consumption 70mA Nominal / 300mA IR ON
Operating Temperature
-10
℃
to 50
℃
(14
℉
~122
℉
)
Operating Humidity 30% to 80%
Lens Pinhole Lens 3.7mm
Dimensions
Body: 62(W) x 90(H) x 48(D)mm / 2.44”(W) x 3.54”(H) x 1.89”(D)
Mount adds minimum 27mm/1.06” to depth (see drawing)
Weight 120 g (4.23 oz)
Certifications CE / FCC
Cable Specifications
