EverFocus EHD300 - Specifications

SPECIFICATIONS
Pickup Device 1/3'' SONY Super HAD CCD
Video Format NTSC or PAL
NTSC: 525 TV lines, 60 fields/sec.
Scanning System
PAL: 625 TV lines, 50 fields/sec.
Picture Elements 768 x 494(NTSC) ; 752 x 582(PAL)
Horizontal Resolution 520TVL
Sensitivity 0.4Lux/F=1.2
S/N Ratio Over 48dB (AGC off)
Electronic Shutter 1/50(1/60)~1/100,000
Vari-focal lens, Auto Iris
f=2.9~10mm
f=3.7~12mm
Lens Type
f=9~22mm
Auto Gain Control ON/OFF Switch
Flickerless
ON/OFF Switch
H-Mirror ON/OFF Switch
Day/Night Mode ON/OFF Switch
Auto White Balance
Yes
Gamma Correction 0.45
2 video outputs
BNC 1.0Vp-p, 75ohm
Video Output
Additional testing video output 1.0Vp-p, 75ohm
Sync. Mode Internal sync
Weatherproof IP66
Vandal Resistant Yes
Power Source 12VDC/24VAC
24VAC: 4W max.
Power Consumption
12VDC: 2W max.
130mm(W) x 98.8mm(H) x 130mm(D);
Dimensions
5.1"(W) x 3.87"(H) x 5.1"(D)
Weight 0.8kg ; 1.8lbs
Operating Temperature -10°C~50°C ; 14°F~122°F (20%~80% Humidity)
Certifications FCC/CE
