HD Solutions
EPH5212
Outdoor 1080 HDcctv PTZ
Features
• 2.1 Megapixel 1920 x 1080
• True Day/Night function with removable IR cut lter
• High Sensitivity for improved image quality at night
• BLC & Electronic WDR functions handle bright and
unbalanced lighting conditions
• Digital Auto Flip function
• Digital Slow Shutter (DSS)
• Motion Detection function
• 12x Optical Zoom & 10x Digital Zoom
• 2 Autofocus Modes (Continuous & One Touch)
• Programmable presets, scan zones, patterns, tours,
and smart privacy masks, including combinations of
functions
• 4 alarm inputs and 1 alarm output
• Power Input Surge Protection built-in
• IP66 weather resistant rating means that it will
withstand the elements in outdoor conditions
• Pan 360° Endless Rotation / 180° Tilt
• Wall Mount Arm Included
EPH5212: Outdoor 12x PTZ with HD Zoom
11
1920
x
1080
2.1
Megapixel
True D/N
Weather
24VAC
Motorized
Lens
OSD
3D
Noise
Reduction
12x
Optical
10x
Digital
Dual
HDcctv
& SD
Output
Part Number EPH5212
Image Area Size 1920 x 1080: Ф 5.52mm; (w x h) 4.8 x 2.7mm
Pickup Device 2.1 Megapixel Sony Exmor R CMOS
Video Format
HD: 1920 x 1080 (Full Hd, 1080P @ 30/25 FPS), HD: 1280
x 720 (HD, 720p @ 60/50 FPS), SD: NTSC/PAL
Picture Elements Full time composite analog output (NTSC/PAL)
Sensitivity 0.2 lux/f=1.6 DSS off color; 0.1 lux ICR removed
S/N Ratio 50 dB
Video Output HDcctv, Full Time SD
Electronic Shutter Auto/Manual Selectable
Digital Slow Shutter Programmable Off or 2x-64x; max 8x recommended
Lens Type
12x Optical/ 5mm wide-60mm tele, Optical view angle
~52.4° (wide) to ~4.64° (tele)
Zoom Ratio 12x Optical and 10x digital zoom with Auto Focus
True Day/Night True Day/Night with Auto ICR function
Backlight
Compensation
On/Off selectable
AGC Yes (Level 0-186)
WDR Electronic WDR (On/Off)
White Balance ATW/Push/Manual/Specic Color or Color Temperature
Motion Detection Yes
Privacy Zone Masking Yes (8 zones)
Focus Control
Off/manual, full auto or ‘one touch’ (holds focus after intial
setting after movement)
Horizontal Rotation
Range
Pan: Speed up to 360°/sec; continuous 360° rotation
Auto Pan Speed
Maximum 0.75 seconds present recall time; manual speed
proportional to zoom ratio
Preset Position
up to 210 positions may be stored; programmable preset
speed
Tour Up to 8 tours (consisting of presets, patterns and scans)
Alarm
4 NO/NC programmable trigger inputs; programmable
relative priority of alarms.
Built-in Menu
Functions
Yes, OSD menu (controlled via RS-485; optional password
protection)
Communication RG59 and RS-485
Communication
Speed
2400 ~ 38,400 baud rate
Built-in Protocols EVF-1, Pelco-P,Pelco D
Speed Dome Address Address Range 00 ~ 99
Manual Pan/Tilt Speed
Tilt: Speed up to 260°/sec; 180° range (± 90°); digital auto
ip for continuous tracking
Weather Resistant
Rating
IP66
Power Source 24VAC +/- 10%
Power Consumption ~850mA heater off; ~1.8A heater on
Operating
Temperature
-40°C ~ 50°C / -40°F ~ 122°F (heater on below ~30°F)
Dimensions
Body diameter 6.55”; height with wall arm 10”, clear bubble
diameter 4.7”, projection from rear with wall arm 13.4”
(10.2” to center line of dome)
Weight 4.9 lbs
Certication FCC, CE, HDcctv Alliance base-line compliance
