EMD935F Outdoor Mobile IR Mini Ball Camera
10
4. Configuration in the OSD Menu
You can configure camera settings in the OSD menu from DVR end. For details on the OSD menu
structure as below:
No. Main Sub Menu Sub Menu / Function
1 Lens Manual
2 Exposure
Shutter
NTSC: 1/30, 1/60, FLK, 1/240, 1/480, 1/1000, 1/2000, 1/5000,
1/10000, 1/50000, X2, X4, X6, X8, X10, X15, X20, X25, X30, Auto
PAL: 1/25, 1/50, FLK, 1/200, 1/400, 1/1000, 1/2000, 1/5000,
1/10000, 1/50000, X2, X4, X6, X8, X10, X15, X20, X25, X30, Auto
AGC 0 – 15
Sens-up
Off
Auto Sens-up
X2, X4, X6, X8, X10, X15, X20, X25,
X30
Brightness 1-100(40)
D-WDR
Off
On Level 0-8
Auto
Defog
Off
Auto
Pos/Size
Position, Size,↑,↓,→,←
Gradation 0-2
Default
3 Backlight
Off
BLC
Level Middle, High, Low
Area
Position, Size,↑,↓,→,←
Default
HSBLC
Select Area1, Area2, Area3, Area4
Display
Off
On
Position, Size,↑,↓,→,←
Black Mask On/Off
Level 0-100
Model
All Day
Night AGC Level 0-255
Default
4
White
Balance
ATW
AWC→SET
