9. OSD MANUAL
• IMAGE
- SHARPNESS:
Using Left / Right button, adjust sharpness value.
- IMAGE FLIP:
Using Left / Right button, select Flip modes – OFF, H FLIP, V FLIP and H/V FLIP.
- DNR:
Using Left / Right button, select Digital Noise Reduction Modes - OFF, LOW, MID, HIGH.
- GAMMA:
Using Left / Right button, adjust gamma control setting.
• SPECIAL
- SYSTEM INFO
Display Camera Version, SDI IF F/W Version &
other information.
[ SPECIAL ]
