9. OSD MANUAL
• ICONS
- : Value adjustment(use LEFT/RIGHT button).
- : Select Sub Menu(use SET button).
- : Execution command(use SET button).
- : Return to previous menu.
- : Menu OFF.
- : Information.
The [SETUP] menu will show up when you push the SET button.
• Main Menu
- VIDEO OUT :
Select SDI Out format and TV Out format.
- LENS :
Select the IRIS TYPE and adjust IRIS control value.
- EXPOSURE :
Adjust Exposure control.
- WHITE BALANCE :
Adjust White balance control.
- DAY / NIGHT :
Day / Night control.
- IMAGE :
Apply Image processing effects.
- SPECIAL :
System setting, IO setting, USER SET setting
- EXIT :
Close OSD Menu.
- SAVE & EXIT :
Save and Close OSD Menu. These settings are
loaded and applied automatically when the Camera
is power on.
[ SETUP ]
VIDEO OUT
LENS
EXPOSURE
WHITE BALANCE
DAY / NIGHT
SPECIAL
EXIT
SAVE & EXIT
720p 60Hz
DC IRIS
AUTO
AUTO
