2. NAMES AND FUNCTIONS OF PARTS
2.1 Front panel
Light Sensor
TAKE CARE NOT TO OBSTRCUT THIS OPENING
WITH THE BODY OF THE LENS!
The light sensor is for optional control of D/N switching levels in some applications. See section 5.6 for
details.
2.2 Top/Bottom Mounting
Using the two phillips head screws provided, the mounting bracket may be mounted to the top of
the camera body for suspending the camera; or, the brackets may be mounted to the bottom of the
camera body to support the camera.
Bottom Bracket
Top Bracket
- 4 -
