1.3 Specifications
Items Parameter
Pickup Device 1/3” SONY Super HAD CCD
Video Format NTSC or PAL
Scanning System
NTSC:525 TV lines, 60 fields/sec
PAL:625 TV lines, 50 fields/sec.
Picture Elements 768 x 494(NTSC); 752 x 582 (PAL)
Horizontal Resolution 520 TV lines
Sensitivity 0.4 Lux / F=1.2(IR OFF) ; 0 Lux (IR ON)
S/N Ratio Over 48 dB(AGC Off )
Electronic Shutter 1/50(1/60)~1/100,000
Lens Type Vair-focal lens, f=2.9~10mm , f=9~22mm
Back Light Comp. Yes
Auto Gain Control Yes
Auto White Balance Yes(2500°K ~9000°K)
True Day & Night Yes
Gamma Correction 0.45
Video Output BNC 1.0Vp-p, 75ohm
Sync. Mode Internal sync.
Power Source 12VDC/24VAC
Power Consumption
12VDC:12W max. (Heater On & IR LED On)
24VAC:15W max. (Heater On & IR LED On)
Dimensions
88mm(W) x 235.3mm(D) x 174.2mm(H);
3.46”(W)x 9.26”(D) x 6.86”(H)
Weight 1.15kg ; 2.53lbs
Operating Temperature -40℃ ~ 50℃; -40℉~122℉ (20%~80% Humidity)
IR Distance 30M / 98 feet
IR Wavelength 850nm
IR LED Lifespan 20,000 hours
Weatherproof IP66
Vandal Resistant Yes
Heater Yes, built-in
Certifications FCC/CE
