-6-
4. WiFi Module Installation on EMV400S FHD
1. Unscrew the four screws on the rear-panel. Pull out the Main Board from
the housing.
2. Screw the Metal Plate onto the Pillars on the Main Board.
a. Find the 2 Pillars on the Main Board and then place the 2 Plastic Spacers
on the 2 Pillars.
Plastic Spacer
Pillar on the Main Board
