80
Exterior Equipment
Stern Seats in the Casting Platform Position
When the backrests are in the seat position, the
seat cushions can be removed to provide access to
the port and starboard stern bilge and equipment
installed there. The batteries, fuel lter, fresh
water pump and raw water pump are among the
equipment installed in the compartments below
the stern seats.
The following is the procedure to remove and
replace the stern the stern seat cushions to
access the bilge:
Removing the seat cushions:
1. Fold the seat backrests down to the casting
platform position. Make they are not latched.
2. Simultaneously lift the rear of the seat and
slide it toward the stern until the front of the
seat can be lifted out of the seat base.
3. Hold the front of the seat slightly above the
seat base and slide it forward until it clears
the seat base and bolster.
Replacing the seat cushion:
1. Align the seat slightly above the seat base and
below the bolster.
2. While lifting the seat assembly just enough
to clear the seat base, slide it in as far as it
will go.
3. Simultaneously lift the rear of the seat and
slide it toward the stern until the retainer at
the front drops below the seat base.
4. Push the rear of the seat down to slide the
cushion into position. The retainer at the front
of the seat cushion will automatically slide be-
low the top of the seat base as the seat slides
into place, securing the seat.
Notice:
Periodically inspect the seat latches and
supports for wear, damage or loose t. Any
problems should be corrected immediately.
PASSENGERS SITTING OR STANDING ON THE REAR DECK
WHILE THE BOAT IS CRUISING COULD LOOSE THEIR BALANCE
AND FALL OVERBOARD INTO THE BOAT PROPELLER OR BE
LOST IN OPEN WATER. ALWAYS MAKE SURE PASSENGERS
RIDING IN THE REAR OF THE COCKPIT ARE PROPERLY SEATED
IN THE STERN SEATS WHENEVER THE BOAT IS UNDERWAY.
Stern Seats in the Seat Position
Starboard Stern Seat Removed
