6
ASSEMBLY PACK CHECK LIST
STEP 1
STEP 2
STEP 3
#66. M5 × 10m/m
Phillips Head Screw
(4pcs)
#103. 3/8" × 3/4"
Hex Head Bolt (2pcs)
#60. 3/8" × 2-1/4"
Hex Head Bolt (1pc)
#96. 3/8" × 2T
Split Washer (1pc)
#79.5/16"×23×1.5T
Flat Washer(2pcs)
#59. 5/16"×15mm
Hex Head Bolt (2 pcs)
#83. Ø 17 Wave
Washer (2 pcs)
#84. 3/8" × 23 × 1.5T
Curved Washer (2pcs)
#104. 5/16" × 1-1/4"
Hex Head Bolt (2 pcs)
#80. 5/16" × 20× 1.5T
Flat Washer (2 pcs)
#71. 5/16" × 7T
Nyloc Nut (2 pcs)
