3. Technical Specification
Performance Specification
Features Description
General
L1 1575.42MHz, C/A code, 12-channel, Carrier-Aided with HWTrack©
Sensitivity
-143 dBm minimum
Update Rate
1Hz
Accuracy
Position: 15m CEP without S/A
Velocity: 0.1m/sec without S/A
Time: ± 100ns synchronized to UTC time
WAAS Accuracy
Position: 3m CEP
Velocity: 0.05m/sec
Acquisition
Cold start: 45sec (average)
Warm start: 38sec (average)
Hot start: 8sec ( average )
Reacquisition
0.1 sec
DGPS
WAAS/EGNOS
Dynamics
Altitude: -1000m to 18000m
Velocity: 500m/sec
Acceleration: ±4g
Antenna
Built-in Patch Antenna
Environmental Specification
Features
Description
Operation Temperature
-30
o
C to +80
o
C degrees Celsius
Storage Temperature
-40
o
C to +90
o
C degrees Celsius
Operating Humidity
5% to 95%
Physical characteristics
Features
Description
Input current
Maximum 150 mA
Dimensions
Diameter: 83.3mm or 3.27-inch, Height: 60mm or 2.36-inch
Weight
8.46oz or 240g
