Everwarm EW18NM - Page 18

18
Figure 24– Incorrect Flame Pattern with
Control Knob Set to High Flame
More than 8” Above Top of Logs
INSPECTING BURNERS
Check pilot ame pattern and burner ame patterns often.
PILOT FLAME PATTERN
Figure 19 shows a correct pilot ame pattern. Figure 20 shows an incorrect pilot ame pattern. The incorrect pilot
ame is not touching the thermocouple. This will cause he thermocouple to cool. When the thermocouple cools,
the heater will shut down.
If pilot ame pattern is incorrect, as shown in Figure 20:
• Turn heater off (see “To Turn Off Gas To Appliance”).
• See Troubleshooting, page 20.
Figure 19 – Correct Pilot Flame Pattern -
EW18/24NM,EW18/24NV Models
Figure 20– Incorrect Pilot Flame Patter-
EW18/24NM,EW18/24NV Models
Figure 23– Correct Flame Pattern with
Control Knob Set to High Flame
More than 3-6” Above Top of Logs
BURNER FLAME PATTERN
Figure 23 shows a correct burner ame pattern. Figure 24 shows an incorrect burner ame pattern. If burner
ame is incorrect:
• Turn heater off.
• See Troubleshooting, page 20.
BURNER PRIMARY AIR HOLES
Air is drawn into the burner through the holes in the tting at the entrance to the burner. These holes may
become blocked with dust or lint. Periodically inspect these holes for any blockage and clean as necessary.
Blocked air holes will create soot.
Figure 21 – Correct Pilot Flame Pattern
EW18/24PM,EW18/24PV Models
Figure 22– Incorrect Pilot Flame Pattern
EW18/24PM,EW18/24PV Models
Thermocouple
Pilot Burner
Thermocouple
Pilot Burner
Pilot Burner
Pilot Burner
Thermocouple
Thermocouple
