500W / 600W 700W Bronze Power Supply User Manual
Installation
STABLE POWER
The 500BQ / 600BQ / 700BQ has outstanding electrical performance with ultra stable voltage and extremely clean
power output. This can help you achieve the highest possible overclock (optional) and provide the most stable
and reliable power to all components. The 500BQ / 600BQ / 700BQ also provides up to 85% (115VAC) / 88%
(220VAC~240VAC) efficiency and is 80 PLUS
®
BRONZE certified.
TOP QUALITY PROTECTIONS
The 500BQ / 600BQ / 700BQ comes equipped with the most comprehensive protection set possible, including Over Voltage
Protection (OVP), Under Voltage Protection (UVP), Over Power Protection (OPP), Short Circuit Protection (SCP),
and Over Current Protection (OCP). 500BQ/600BQ is also covered by a 3-year warranty and 700BQ is covered by
a 5- year warranty with EVGA’s legendary customer service and support.
MODULAR DESIGN
Reduce clutter in the case, improve ambient temperatures with better airflow overall and provide a clean look to
any system. Modular PSU designs allow the user to disconnect the cable from the power supply side if they
are not needed for the specific configuration. This can help free up space inside the case and improve cable
management as well as airflow throughout the system.
Features
1. Remove the power supply from its packaging.
2. Use the screws provided with your case to install the power supply into
your computer. NOTE: It is recommended to install the power supply with
the fan facing down. However, if your case places the power supply at the
bottom of the case and there are no ventilation holes available, it may be
best to install the power supply with the fan facing up for greater efficiency
and reliability.
3. Connect the 20+4-Pin ATX cable to the motherboard.
English
3
