EVGA 500 BQ - EVGA 500 BQ; 600 BQ; 700 BQ Specification

Over Voltage Protection, Under Voltage Protection, Short Circuit Protection, Over Power
Protection, Over Current Protection.
Dimensions: 85mm (H) x 150mm (W) x 140mm (L)
EVGA 500BQ / 600BQ / 700BQ Cable Configuration
500W BRONZE
AC Input
DC Output
MAX output, A
Combined, W
Output power,
Pcont
100-240 VAC, 8-4A, 60 / 50Hz
+5V +3.3V +12V -12V +5Vsb
20A 20A 41.6A 0.3A 2.5A
110W 499.2W
3.6W 12.5W
500W
600W BRONZE
AC Input
DC Output
MAX output, A
Combined, W
Output power,
Pcont
100-240 VAC, 10-5A, 60 / 50Hz
+5V +3.3V +12V -12V +5Vsb
20A 20A 50A 0.3A 2.5A
120W 600W
3.6W 12.5W
600W
700W BRONZE
AC Input
DC Output
MAX output, A
Combined, W
Output power,
Pcont
100-240 VAC, 12-6A, 60 / 50Hz
+5V +3.3V +12V -12V +5Vsb
20A 20A 58.3A 0.3A 2.5A
130W 699.6W
3.6W 12.5W
700W
500W / 600W 700W Bronze Power Supply User Manual
English
6
