MB 1 x ATX 24-Pin
2 x EPS/ATX12V 8(4+4)-Pin
1 x PCI-E 8(6+2)-Pin x 2
2 x PCI-E 8(6+2)-Pin
3 x SATA 5-Pin x 3
1 x Molex 4-Pin x 4
VGA1
VGA2
VGA3
CPU1
CPU2
PERIF1
FDD
SATA1
SATA2
SATA3
1 x Molex to FDD Adapter
750W / 850W / 1000W GOLD Power Supply User Manual
7
English
Dimensions: 85mm (H) x 150mm (W) x 165mm (L)
SuperNOVA 850G2L Cable Configuration
Modular Connector Cables Cable Color
Black
Over Voltage Protection, Under Voltage Protection, Short Circuit Protection,
Over Power Protection, Over Current Protection
SuperNOVA 850G2L Specifications
850W GOLD
+50°C ambient @ full load
AC Input
100-240 VAC, 10A, 60/50 Hz
DC Output +5V +3.3V +12V -12V +5Vsb
MAX output, A
24A 24A 70.8A 0.5A 3.0A
Combined, W
120W 849.6W
6W 15W
Output power,
Pcont
850W @ +50°C
GOLD
