EVGA SUPERNOVA GT Series User Manual

6
English
1000W / 1300W GOLD
Power Supply User Manual
SuperNOVA 1000 / 1300 GT Cable Configuration
Modular Connector Connector Per Cable Cable Qty
MB ATX 24-Pin x 1 1
CPU1,CPU2
VGA1,VGA2,VGA3,
VGA4,VGA5
SATA1,SATA2,SATA3,
SATA4
PERIF Molex 4-Pin x 4 1
FDD Molex to FDD Adapter 1
1000 GT
EPS/ATX12V 8(4+4)-Pin x 1 2
PCI-E 8(6+2)-Pin x 1 2
SATA 5-Pin x 3 4
PCI-E 8(6+2)-Pin x 2 3
l
7
English
1000W / 1300W GOLD
Power Supply User Manuall
Dimensions: 86mm (H) x 150mm (W) x 150mm (L)
Dimensions: 86mm (H) x 150mm (W) x 180mm (L)
Protection: Over Voltage Protection (OVP), Under Voltage Protection (UVP), Short Circuit Protection (SCP),
Over Power Protection (OPP), Over Current Protection (OCP), Over Temperature Protection (OTP).
SuperNOVA 1000 / 1300 GT Specifications
AC Input
DC Output
MAX output, A
Combined, W
Output power, P
cont
100-240V~, 12-6A, 60/50Hz
+5V
+3.3V +12V -12V +5Vsb
25A 25A 83.3A 0.5A 3A
130W 1000W
6W 15W
1000W @ +50°C
SuperNOVA 1000 GT
AC Input
DC Output
MAX output, A
Combined, W
Output power, P
cont
100-240V~, 15-8A, 60/50Hz
+5V
+3.3V +12V -12V +5Vsb
25A 25A 108.3A 0.5A 3A
130W 1300W
6W 15W
1300W @ +50°C
SuperNOVA 1300 GT
Modular Connector Connector Per Cable Cable Qty
MB ATX 24-Pin x 1 1
CPU1,CPU2
VGA1,VGA2,VGA3,
VGA4,VGA5,VGA6
SATA1,SATA2,SATA3,
SATA4
PERIF1,PERIF2 Molex 4-Pin x 4 2
FDD Molex to FDD Adapter 1
1300 GT
EPS/ATX12V 8(4+4)-Pin x 1 2
PCI-E 8(6+2)-Pin x 1 4
SATA 5-Pin x 3 4
PCI-E 8(6+2)-Pin x 2 2

EVGA SUPERNOVA GT Series Specifications

General

Form Factor	ATX
Efficiency Rating	80 PLUS Gold
Modular	Fully Modular
Wattage	650W, 750W, 850W, 1000W
Fan Size	135mm
Protection Features	OVP, UVP, OCP, OPP, SCP, OTP
ATX Connector	1 x 24-Pin
Type	ATX12V
Warranty	7 Year
Dimensions	150mm x 150mm x 86mm
Molex Connectors	650 GT: 3x , 750 GT: 3x , 850 GT: 3x , 1000 GT: 3x
