EVGA SUPERNOVA P3 Series User Manual

6
English
1000W / 1200W PLATINUM
Power Supply User Manual
l
7
English
1000W / 1200W PLATINUM
Power Supply User Manuall
Dimensions: 86mm (H) x 150mm (W) x 180mm (L)
Protection: Over Voltage Protection (OVP), Under Voltage Protection (UVP), Short Circuit Protection (SCP),
Over Power Protection (OPP), Over Current Protection (OCP), Over Temperature Protection (OTP).
SuperNOVA 1000 / 1200 P3 Specifications
AC Input
DC Output
MAX output, A
Combined, W
Output power, P
cont
100-240V~, 12-6A, 60/50Hz
+5V
+3.3V +12V -12V +5Vsb
25A 25A 83.3A 0.5A 3A
125W 1000 W
6W
15W
1000W @ +50°C
SuperNOVA 1000 P3
AC Input
DC Output
MAX output, A
Combined, W
Output power, P
cont
100-240V~, 14-7A, 60/50Hz
+5V
+3.3V +12V -12V +5Vsb
25A 25A 100A 0.5A 3A
125W 1200W
6W 15W
1200W @ +50°C
SuperNOVA 1200 P3
SuperNOVA 1000 / 1200 P3 Cable Configuration
1000 P3
Modular Connector Connector Per Cable Cable Qty
MB ATX 24-Pin x 1
1
CPU1,CPU2
VGA1,VGA2,VGA3,VGA4
VGA5,VGA6
SATA1,SATA2,SATA3,
SATA4
PERIF Molex 4-Pin x 4 1
FDD Molex to FDD Adapter 1
EPS/ATX12V 8(4+4)-Pin x 1
2
PCI-E 8(6+2)-Pin
4
SATA 5-Pin x 3
4
PCI-E 8(6+2)-Pin x 2
2
1200 P3
Modular Connector Connector Per Cable Cable Qty
MB ATX 24-Pin x 1
1
CPU1,CPU2
VGA1,VGA2,VGA3,VGA4
VGA5,VGA6
SATA1,SATA2,SATA3,
SATA4
PERIF1,PERIF2 Molex 4-Pin x 4 2
FDD Molex to FDD Adapter 1
EPS/ATX12V 8(4+4)-Pin x 1
2
PCI-E 8(6+2)-Pin
4
SATA 5-Pin x 3
4
PCI-E 8(6+2)-Pin x 2
2
