Page #3 background imageLoading...
Page #3 background image
3
English
1300W / 1600W
Power Supply User Manual
English
1300W / 1600W
Power Supply User Manual
Installation
Features
STABLE POWER
The P+ series has outstanding electrical performance with ultra stable voltage and extremely clean power output.
This can help you achieve the highest possible overclock (optional) and provide the most stable and reliable power
to all components. The P+ series also has high efficiency up to 92% (115V~) / 94% (230V~) efficiency and is 80
PLUS
®
PLATINUM certified.
ECO THERMAL CONTROL SYSTEM
The EVGA ECO Intelligent Thermal Control System provides silent operation at low loads, improved efficiency
and longer life span of the fan. Enabled by a simple switch directly on the power supply, the “No Fan Spin” feature
is ideal for users looking to reduce ambient noise overall. Save on energy costs and unnecessary fan usage with
the EVGA ECO Thermal Control System.
TOP QUALITY PROTECTIONS
The P+ series comes equipped with the most comprehensive protection set possible, including Over Voltage
Protection (OVP), Under Voltage Protection (UVP), Over Power Protection (OPP), Short Circuit Protection (SCP),
Over Current Protection (OCP), and Over Temperature Protection (OTP). This product is also covered by an
exceptional 10-year warranty and EVGA’s legendary customer service and support.
SUPERIOR BUILD QUALITY
The P+ series is built to the highest standards, using 100% Japanese capacitors rated at 105 degrees Celsius
and high quality brand-name semiconductor components for the highest performance and reliability. The Ultra
Quiet 135mm fan provides adequate cooling to allow near silent operation.
MODULAR DESIGN
Reduce clutter in the case, improve ambient temperatures with better airflow overall and provide a clean look
to any system. Modular PSU designs allow the user to disconnect the cables from the power supply side if they
are not needed for the specific configuration. This can help free up space inside the case and improve cable
management as well as airflow throughout the system.
1. Remove the power supply from its packaging.
2. (Optional) Using the provided PSU testing tool, connect the 24-Pin cable to the
PSU, then attach the testing tool to the 24-Pin cable. Connect the ATX power cable
to the PSU and plug the PWR cable into the outlet or surge protector/UPS you plan
to use. Once connected, turn the power switch to the ON position.
Please note: If you are using a water cooling configuration, this testing tool
provides a simple, safe, option for bleeding/draining/testing water cooling
components without the need of a paperclip or other device.
Introduction: Premium Power
Thank you for purchasing an EVGA
®
P+ 80 PLUS
®
Platinum series power supply. The 1300 / 1600 P+ is a high
quality power supply that offers great value to gamers / system builders. The modular design provides custom cable
configurations for any application, and due to the ultra silent 135mm fan, the 1300 / 1600 P+ series reduces heat
during heavy load while keeping the decibel level down. Designed with stability and durability in mind 1300 / 1600
P+ series is the perfect choice to power your systems.
2
What’s in the Box
Included with your EVGA 1300 / 1600 P+ power supply are the following items for proper installation and optional
testing:
1300 P+
(1) EVGA Power Supply
(1) EVGA Manual
(4) Mounting Screws
(1) EVGA PSU Tester (24-Pin)
(1) 24-Pin ATX Cable
(2) 8(4+4)-Pin EPS / ATX 12V CPU Cables
(4) 8(6+2)-Pin PCI-E VGA Cables
(2) 2 x 8(6+2)-Pin PCI-E VGA Cables
(4) 3 SATA Cables
(2) 3 Molex Cables
(1) Molex to FDD Adapter
(1) Power Cord Cable (optional)
1600 P+
(1) EVGA Power Supply
(1) EVGA Manual
(4) Mounting Screws
(1) EVGA PSU Tester (24-Pin)
(1) 24-Pin ATX Cable
(2) 8(4+4)-Pin EPS / ATX 12V CPU Cables
(4) 8(6+2)-Pin PCI-E VGA Cables
(5) 2 x 8(6+2)-Pin PCI-E VGA Cables
(2) 3 SATA Cables
(2) 4 SATA Cables
(2) 4 Molex Cables
(1) 2 Molex to FDD Adapter
(1) Power Cord Cable (optional)
Safety Information
WARNING 1: This unit has no user-serviceable parts inside. Opening the casing presents a risk of electrocution and will void the product’s
warranty. EVGA will not be responsible for any result of improper use, including but not limited to, any use of the product outside of its intended
purpose or use inconsistent with the warranty terms available online. (Warranty information is available at www.evga.com/support/warranty and
this manual is available at www.evga.com/manuals).
WARNING 2: NOT ALL MODULAR CABLES ARE THE SAME OR COMPATIBLE! Use of a non-officially supported cable may void your warranty,
cause a Power Supply failure, and/or cause damage to connected devices. Please use ONLY officially supported cables included with the Power
Supply, or an officially supported set of alternative cables listed for your specific model of Power Supply made BY EVGA. EVGA will NOT be
responsible for damages caused to your power supply, devices, or non-officially supported modular cables in the event damage is caused by
your use of non-officially supported modular cables.
