EVGA SUPERNOVA P+ Series User Manual

6 7
English
1300W / 1600W
Power Supply User Manual
English
1300W / 1600W
Power Supply User Manual
Over Voltage Protection, Under Voltage Protection, Short Circuit Protection, Over Power Protection,
Over Current Protection, Over Temperature Protection.
EVGA 1300 / 1600 P+ Specifications
1300 P+
AC Input
100-240V~, 15-8A, 60/50Hz
DC Output
+5V
+3.3V
+12V -12V +5Vsb
MAX output, A
24A 24A 108.3A 0.5A 3A
Combined, W
120W 1299.6W
6W 15W
Output power,
Pcont
1300W @ +50°C
EVGA 1300 P+ Cable Configuration
Modular Connector Cable Qty
MB
Cable Color
ATX 24-Pin
Black
EPS/ATX12V 8(4+4)-Pin
PCI-E 8(6+2)-Pin
PCI-E 8(6+2)-Pin x 2
SATA 5-Pin x 3
VGA1,VGA2,VGA3,VGA4,VGA5,
VGA6
CPU1,CPU2
PERIF1,PERIF2
FDD
SATA1,SATA2,SATA3,SATA4
Molex 4-Pin x 3
Molex to FDD Adapter
Dimensions: 86mm (H) x 150mm (W) x 200mm (L)
EVGA 1600 P+ Cable Configuration
Modular Connector
MB
Cable Color
ATX 24-Pin
Black
EPS/ATX12V 8(4+4)-Pin
PCI-E 8(6+2)-Pin
PCI-E 8(6+2)-Pin x 2
SATA 5-Pin x 3
SATA 5-Pin x 4
Molex 4-Pin x 4
VGA1,VGA2,VGA3,VGA4,VGA5,
VGA6,VGA7,VGA8,VGA9
CPU1,CPU2
PERIF1,PERIF2
FDD
SATA1,SATA2,SATA3,SATA4
Molex to FDD Adapter x 2
Connector Per Cable
1
4
2
2
4
2
1
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Connector Per Cable
Cable Qty
1
4
2
5
2
2
2
1
1600 P+
AC Input
115-240V~, 17-9A, 60/50Hz
DC Output
+5V
+3.3V
+12V -12V +5Vsb
MAX output, A
25A 25A 133A 0.5A 4A
Combined, W
150W 1596W
6W 20W
Output power,
Pcont
1600W @ +50°C

EVGA SUPERNOVA P+ Series Specifications

General

Brand	EVGA
Model	SUPERNOVA P+ Series
Category	Power Supply
Language	English
