WATER PUMP KITS (Evinrude 115 – 130 HP)
DISASSEMBLY
Rotate the driveshaft counterclockwise to unlock
the impeller key. Remove the four impeller
housing screws.
Slide the water pump off the driveshaft. Remove
the impeller key, O-ring, impeller plate, and
gasket.
Make sure gasket surface is clean and smooth.
B
B
60-84 In. lbs.
(7-9.5 N·m)
A
C
B
A
A
A
C
10
6
5
4
3
2
1
8
7
9
11
A
D
C
007171
Ref P/N Name of Part Qt
y
- 5007556 WATER PUMP REPAIR KI
T
1
1 338484 *GASKET, Im
p
eller
p
late 1
2 338485 *PLATE, Im
p
eller hs
g
-
(
Stainless
)
1
3 331353 *SEAL, Im
p
eller housin
g
p
late 1
4 5001593 *IMPELLER Ass
y
1
5 302035 **O-RING, Im
p
eller to
p
late 1
6 331107 **KEY, Im
p
eller 1
7 338486 *CUP, Im
p
eller-
(
Stainless
)
1
8 331188 *O-RING, Cu
p
to housin
g
1
9 5007554 *IMPELLER HOUSING 1
10 302325 *SCREW, Im
p
eller housin
g
4
11 353690 *GROMMET, Pum
p
to exh housin
g
1
A
Tri
p
le-Guard Grease
B
Gasket Sealin
g
Com
p
ound
C
Adhesive 84
7
D
Mol
y
Lub
e
1. Screws 007173
1
1
1
1. Gasket surface 007174
1
