Evo FX4M - TREADMILL ASSEMBLY; STEP 1: Attach Uprights to Base Frame.

FX4M MOTORIZED TREADMILL
Visit us at: www.evofitness.com
11
ASSEMBLY
STEP 1:
Remove your treadmill from the carton and place it on the floor in an open area as shown in FIG-1.
First make sure to connect the wires. Then insert the Left and Right Handle Uprights (21 and 22) into the base Frame (46)
and secure with 6 x 13mm Washers (25), M6 x 55mm Screws (24), Plastic Caps (26) and M8 x 15mm Screws (27).
