Evo FX4M - Parts List

FX4M MOTORIZED TREADMILL
Visit us at: www.evofitness.com
6
PARTS LIST
No. Description Qty. Order No. No. Description Qty. Order No.
1 Computer 1 FX4M-01 30
Base Frame End Cap –
Left
1
1 FX4M-30
2 Safety Key 1 FX4M-02 31
Base Frame End Cap –
Left
2
1 FX4M-31
3 Computer Support 1 FX4M-03 32
Base Frame End Cap –
Right
1
1 FX4M-32
4 M6 x 15mm Console Screw 2 FX4M-04 33
Base Frame End Cap –
Right
2
1 FX4M-33
5 Plastic Ring 1 FX4M-05 34 M6 x 20mm Screw 2 FX4M-34
6 M5 x 10mm Screw 1 FX4M-06 35 Base Frame End Cap 2 FX4M-35
7 Handle Cover – Left #1 1 FX4M-07 36 M14 x 54MM Screw 2 FX4M-36
8 Handle Cover – Left #2 1 FX4M-08 37 M10 x Nylon Nut 3 FX4M-37
9 Handle Cover – Right #2 1 FX4M-09 38 Topple Bolt 4 FX4M-38
10 Handle Cover – Right #1 1 FX4M-10 39 B# 8 x 43MM Screw 1 FX4M-39
11 #8 x 15mm Screw 34 FX4M-11 40 M14 Nut 2 FX4M-40
12 #4 x 19mm Screw 9 FX4M-12 41 Cushion 4 FX4M-41
13 Hand Pulse Sensor 2 FX4M-13 42 Bushing 6 FX4M-42
14 End Cap 2 FX4M-14 43 Caster Bracket 2 FX4M-43
15 Left Handlebar 1 FX4M-15 44 Lock Washer 2 FX4M-44
16 Right Handlebar 1 FX4M-16 45 Wheel Shaft 2 FX4M-45
17 M8 x 25mm Screw 13 FX4M-17 46 Base Frame 1 FX4M-46
18 M8 x 19mm Screw 4 FX4M-18 47 Caster 2 FX4M-47
19 M8 x 78mm Bolt 2 FX4M-19 48 Cross Tube 1 FX4M-48
20 Metal Cap 2 FX4M-20 49 Screw 1 FX4M-49
21 Left Handle Upright 1 FX4M-21 50 M8 x Nylon Nut 2 FX4M-50
22 Right Handlebar Upright 1 FX4M-22 51 Foot Up Lock 1 FX4M-51
23 M5 x 8mm Screw 4 FX4M-23 52 16 x 8mm Washer 1 FX4M-52
24 M6 x 55mm Screw 2 FX4M-24 53 Spring 1 FX4M-53
25 6 x 13mm Washer 2 FX4M-25 54 Motor Hood - Top 1 FX4M-54
26 Plastic Cap 2 FX4M-26 55 Left Side Strip 1 FX4M-55
27 M8 x 15mm Screw 4 FX4M-27 56 Right Side Strip 1 FX4M-56
28 M5 x 8mm Screw 2 FX4M-28 57 Running Belt 1 FX4M-57
29 Power Switch 1 FX4M-29 58 Rear End Cap 1 FX4M-58
