Evo FX4M - Page 7

FX4M MOTORIZED TREADMILL
Visit us at: www.evofitness.com
7
PARTS LIST
No. Description Qty. Order No. No. Description Qty. Order No.
59 M10 x 35mm Screw 1 FX4M-59 89 Transfer Board 1 FX4M-89
60 Elevation Motor 1 FX4M-60 90 Frame 1 FX4M-90
61 Tube Clamp 2 FX4M-61 91 Micro Switch 1 FX4M-91
62 M5 x 12mm Screw 2 FX4M-62 92 Metal Plate 2 FX4M-92
63 Gear Sleeve 1 FX4M-63 93 M8 x 30 Screw 4` FX4M-93
64 Bumper 1 FX4M-64 94 Cushion 10 FX4M-94
65 U Bracket 1 FX4M-65 95 13 x 6.5 Washer 3 FX4M-95
66 M16 x 54 Screw 1 FX4M-66 96 M6 x 70 Screw 1 FX4M-96
67 Bumper 1 FX4M-67 97 M10 Screw 15 FX4M-97
68 35 x 18mm Washer 1 FX4M-68 98 15 x 8 Washer 10 FX4M-98
69 M16 Nut 1 FX4M-69 99 M8 x 43 Screw 2 FX4M-99
70 22 x 8mm Washer 2 FX4M-70 100 Roller 2 FX4M-100
71 Bumper 1 FX4M-71 101 M6 x 45 Screw 2 FX4M-101
72 M10 x 63mm Screw 1 FX4M-72 102 Rear Roller 1 FX4M-102
73 M8 x 15mm Screw 2 FX4M-73 103 Rear Roller Shaft 1 FX4M-103
74 6 x 13mm Washer 2 FX4M-74 104 Motor Hood - Bottom 1 FX4M-104
75 M10 x Nylon Nut 1 FX4M-75 105 Bushing 4 FX4M-105
76 M10 x 136 Screw 1 FX4M-76 106 Lever Arm Cap - Front 2 FX4M-106
77 M8 x 89mm Bolt 1 FX4M-77 107 Plastic Clamp - Top 2 FX4M-107
78 Motor Holder 1 FX4M-78 108 Plastic Clamp - Bottom 2 FX4M-108
79 Motor 1 FX4M-79 109 Elevation Frame 1 FX4M-109
80 Motor Belt 1 FX4M-80 110 Plastic Cap 2 FX4M-110
81 M3 x 8 Screw 2 FX4M-81 111 Lever Arm Cap – Rear Left 1 FX4M-111
82 Front Roller Shaft 1 FX4M-82 112 Lever Arm Cap – Rear Right 1 FX4M-112
83 Front Roller 1 FX4M-83 113 Pivot Shaft 1 FX4M-113
84 M10 x 30 Screw 8 FX4M-84 114 10mm Lock Washer 2 FX4M-114
85 M4 x 10 Screw 2 FX4M-85 115 Support 1 FX4M-115
86 Spring Bracket 2 FX4M-86 116 Motor Cover Bottom 1 FX4M-116
87 Running Board 1 FX4M-87 117 3/8” x 30mm Screw 2 FX4M-117
88 Control Board 1 FX4M-88 118 Bearing 2 FX4M-118
