Evo FX4M - STEP 4: Attach Cross Tube and Secure Support.

FX4M MOTORIZED TREADMILL
Visit us at: www.evofitness.com
14
ASSEMBLY
STEP 4:
Attach the Cross Tube (48) to the Left and Right Handle Uprights (21 and 22) and secure with the Metal Caps (20) and M8 x
78mm Bolts (19).
Secure the Computer Support (3) to the Left and Right Handle Uprights (21 and 22) by tightening the M8 x 25mm
Screws (17).
