EVO REV 600 ELLIPTICAL TRAINER
Visit us at: www.evofitness.com
10
ASSEMBLY
STEP 3:
Attach the Pedal Arm Front Pivot Covers (18) into the ends of the Action Handle Bar – Right (17) and Pedal Arm – Right
(34). Repeat the procedure on the Pedal Arm – Left (33) and Action Handle Bar – Left (16).
18
18
33
16
17
34
