Evo SP-PRO - WIRELESS REMOTE OPERATIONS; REMOTE BINDING AND USAGE; REMOTE INDICATORS AND CONTROLS; GIMBAL TECHNICAL SPECIFICATIONS

Battery Indicator
4 Flashes = 75-100%
3 Flashes = 50-75%
2 Flashes = 25-50%
Flashes Quickly = 0-25%
Bluetooth Status Indicator
Continuous Flashing = Not Connected
Solid Light = Connected
Flash Once = Device Switch
Charging Indicator
Red = Charging
Green = Fully Charged
Power Switch
UP = Power On
DOWN = Power O
Device Switch
UP = Remote Control
DOWN = Smartphone Control
Multifunction Button
Single click to return gimbal
to original position.
Joystick
Single Click the joystick to switch
between operating modes. Heading
Follow Mode (default) and Heading Lock
Mode.
Double Click the joystick to enter Heading
& Pitch Follow Mode. Single click the
joystick again to exit this mode and return
to previous mode. Please refer to the
Operating Modes section of the manual
for more details.
Remote Specications:
Charging Voltage: 5V
Battery Life: ~30 Hours
Battery Capacity: 150mAh
Transmit/Recieve Current: 11.9mA
Normal Operating Current: 2.8mA
Max Control Distance: ~30’ Feet
Wireless Remote
Binding Instructions
1. Place remote within 5 feet
of gimbal.
2. Hold down the multifunc-
tion button while switching
on the power switch.
3. Bluetooth Indicator light
will rapidly ash while
connecting. Indicator light
will illuminate solid when
connected successfully.
Note: Wireless remote
sold separately.
WIRELESS REMOTE
SPECIFICATIONS
Dimensions: Length： 105mm
Width： 102mm
Height： 278mm
Operating Current: 80mA-6000mA
Operating Temperature: 5F°-115F° (0C°-45C°)
Run-Time: 3-4h
Gimbal Weight: 265g（ no batteries）
Camera Payload: 130g-225g
Tilt, Roll, Pan Axis Range: 360° (unlimited rotation)
Battery: Lithium Ion
Battery Type: NCR 18650
Battery Voltage: 3.7V
USB Charger Current: 800mAh
USB Charger Input Voltage: 5V USB
SPECIFICATIONS
102mm 105mm
278mm
Max Opening 85mm
Min Opening 55mm
