EVO XPLORE ELLIPTICAL TRAINER
Visit us at: www.evofitness.com
9
ASSEMBLY
STEP 1:
Attach the Front and Rear Stabilizers (74 and 72) to the Main Frame (27) using four M8 x 22mm Allen Head Bolts (70),
Spring Washers (84) and Curved Washers (45) as shown. Make sure the screws are tightly fastened.
