EVO XPLORE ELLIPTICAL TRAINER
Visit us at: www.evofitness.com
10
ASSEMBLY
STEP 2:
Attach the Right Foot Pedal (78) onto the Right Foot Pedal Tube (77) using two M8 x 60mm Carriage Bolts (58), M6 x 13mm
Washers (61) and Foot Pedal Knobs (62) as shown. Repeat this procedure to attach the Left Foot Pedal (59) to the Left Foot
Pedal Tube (60). The pedal position is adjustable and can be changed after the unit is fully assembled.
