EVOline BackFlip - General Dimensions; Overall Dimensions; Dimensions for Stainless Steel Surface; Dimensions for Glass Surface

7
3 mm
53 mm
212 mm
212 mm
5 mm
53 mm
225,2 mm
104,8 mm
R 2,5 mm
Abmessungen / General dimensions
8
9 10
8
Abmessungen
9
 AbmessungenmitEdelstahloberäche
10
 AbmessungenmitGlasoberäche
8
General dimensions
9
Dimensions with stainless steel surface
10
Dimensions with glass surface.
