07
IInniittiiaall aapppprrooaacchh
A Output hopper Collects the printed and/or encoded cards.
B Cover lever Enables the printer cover to be opened and closed.
C 100-card Feeder Receives the cards for printing.
D Control Panel Shows the printer activity.
E Manual card feeder (option) Enables the cards to be inserted one by one. E
F Carrying handle
Enables the printer to be carried.
G DB-9 connector(s) (option) Enables data to be received and sent "from" and "to" the computer
or a coupler to be connected for chip cards personalization
H Power supply connector Enables the printer to be connected to its power supply.
I USB computer connector (std) Enables data to be received and sent "from" and "to" the computer.
J RJ45 Ethernet connector (option) Enables data to be received and sent from and to computer(s)
through an Ethernet network.
K Cleaning roller Removes all dust before the cards are printed.
L Card thickness gauge
Enables the adjustment of the cards from 0.25 mm (10 mil) to 1 mm (40 mil).
M Thermal print head Enables the cards to be printed in 300 dpi.
N Identification label Indicates the model and the serial number of the printer as well as
its Mac address (necessary for hooking up to the Ethernet network -
T
CP/IP).
O
Contactless (RFID) card encoding
Enables contactless chip cards to be personalized.
antenna (option)
P
Magnetic encoding head (option)
Enables cards with magnetic tracks 1, 2 and 3 to be encoded.
Q
Smart c
ard contact station (option)
Enabl
e cards with chip to be personalized.
