Evolite EVO SPOT 90 - DMX Mode and Protocol; DMX Channel Functions; Master;Slave Configuration; Maintenance and Service

EVO SPOT 90 Manual Ver. 1.00 Page16
Note. If 2 fixtures are addressed with same DMX value, they will move exactly the same way.
DMX-protocol
15 C h a n n e ls m o d e
DMXch
Function
Value
Description
CH1
Pan
0-255
Rotation 530°
CH2
Tilt
0-255
Rotation 270°
CH3
Pan Fine
0-255
Pan fine
CH4
Tilt Fine
0-255
Tilt fine
CH5
Pan/Tilt Speed
0-255
Speed Pan/Tilt
CH6
Strobe
0-255
Strob effect from slow to fast
CH7
Dimmer
0-255
Dimmer from 0 to 100%
CH8
Color Wheel
0-255
Colors
CH9
Gobo Wheel
0-255
Gobos
CH10
Gobo Shake
0-255
Gobo Shake from slow to fast
CH11
Gobo Rotation
0-255
Gobo rotation from slow to fast
CH12
Prism
0-255
Prism
CH13
Prism Rotation
0-255
Prism rotation
CH14
Focus
0-255
Focus
CH15
Reset
0-255
Reset fact. Presets
o Master/ Slave Mode
Use standard DMX cables to daisy chain your units together via the DMX connector on the rear of the
units.Proper performance it may be necessary to use a terminator at the last fixture. For more information
about terminators.
 Maintenance & service
o Cleaning
The cleaning of internal must be carried out periodically to optimize light output. Cleaning frequency depends
on the environment in which the fixture operates: damp, smoky or particularly dirty surrounding can cause
greater accumulation of dirt on the fixture’s optics.
 Clean with soft cloth using normal glass cleaning fluid.
 Always dry the parts carefully.
 Clean the external optics at least every 20 days.
