1.5
1.51.5
1.5 Serial
SerialSerial
Serial Communication
Communication Communication
Communication Port
PortPort
Port
This serial connector is used for interfacing any RS232 serial peripheral devices.
Example: Barcode reader, GPS provided by Evolute.
1.6
1.61.6
1.6 Battery Charging
Battery ChargingBattery Charging
Battery Charging
Connect the adaptor into the connector shown in the figure1. Battery charging
LED starts to glow indicating the charging condition and once the battery is
charged completely the battery charging LED turns off.
1.7
1.71.7
1.7 Smart Card
Smart CardSmart Card
Smart Card
1.7.1
1.7.11.7.1
1.7.1
Primary Smart card
Smart card has to be inserted from bottom with smart card chip facing
upwards.
1.7.2
1.7.21.7.2
1.7.2
Secondary Smart card
Smart card has to be inserted from top with smart card chip facing
upwards. Smart Card will get completely inserted into the slot in case of
secondary smart card insert.
1.8
1.81.8
1.8 Test Print through switch
Test Print through switchTest Print through switch
Test Print through switch
While the IMPRESS is off (IMPRESS on slide switch is in off position), Press &
hold the wake up switch and switch on the Impress using the slide switch.
1.9
1.91.9
1.9 Wake Up switch
Wake Up switchWake Up switch
Wake Up switch
Impress Device goes to sleep mode/wait mode automatically if no operation is
done for 10 Minutes. Press the wake up switch to wake up the Impress device.
1.10
1.101.10
1.10 Paper Feed switch
Paper Feed switchPaper Feed switch
Paper Feed switch
Pressing this switch feeds the paper by 1.5cm. Press & hold the switch to
continuously feed paper, till switch is released.
1.11
1.111.11
1.11 Finger Print Scanner
Finger Print ScannerFinger Print Scanner
Finger Print Scanner
When communicating with the Finger Print Scanner, finger has to be placed
when LED glows.
2
22
2 C
CC
Conclusion
onclusiononclusion
onclusion
This document describes the Impress Device’s functionality.
