Evolution EVOMAG 28 User Manual

6 7
www.evolutionpowertools.com www.evolutionpowertools.com
FR
ES
EN
SPECIFICATIONS
MACHINE
Motor (UK) 230V ~ 50/60Hz
Motor (UK) 110V ~ 50/60Hz
Motor (USA) 120V ~ 60Hz
Number Of Speeds
Speed (No Load)
Insulation Class
Power Cord Length
Weight
CUTTER CAPACITIES
Maximum Annular Cutting Capacity
Maximum Cutting Depth
Cutter Shank
Standard Twist Drill Capacity
Magnetic Adhesion
Minimum Plate Thickness
DIMENSIONS
Magnet Dimension
Maximum Machine Height
Minimum Machine Height
Machine Width
NOISE & VIBRATION
Sound Pressure Level L
PA
Sound Power Level L
WA
Hand Arm Vibration
MODEL NUMBERS
United Kingdom
United States
Europe
METRIC IMPERIAL
1200W 5A
1200W 11A
1200W 10A
1 1
570min
-1
570rpm
1 1
2.6m 8’ 5”
14kg 31lb
28mm 11/8”
50mm 2”
19mm 3/4”
13mm 1/2”
1300kg f 2860lbs f
10mm 3/8”
50 x 80 x 164mm 2 x 3-1/8 x 6-1/2”
585mm 23”
450mm 17-3/4”
225mm 8-7/8”
85.10 dB(A) K=3 dB(A)
98.10 dB(A) K=3 dB(A)
0.283m/s
2
K=1.5m/s
2
230V: 090-0001 110V: 090-0002
090-0003
090-0004
METRIC IMPERIAL
2000W 8.6A
1700W 15.4A
1700W 15A
2 2
380  500 min
-1
380  500 rpm
1 1
3.5m 11’ 6”
22.9kg 50.38lb
50mm 2”
75mm 3”
19mm 3/4”
16mm 5/8”
3263 kg f 7194 lbs f
12mm 15/32”
100 x 200mm 4 x 8”
610mm 24”
505mm 19-7/8”
310mm 12-1/4”
97 dB(A) K=3 dB(A)
110 dB(A) K=3 dB(A)
ah= 0.4 m/s
2
K=1.5 m/s
2
230V: 092-0001 110V: 092-0002
092-0003
092-0004
METRIC IMPERIAL
2000W 8.6A
1700W 15.4A
1700W 15A
4 4
200/260/390/490 min
-1
200/260/390/490 rpm
1 1
3.5m 11’ 6”
24.8kg 54.5 lb
75mm 3”
50mm 2”
19mm 3/4”
32mm 1-1/4”
3263 kg f 7194 lbs f
12mm 15/32”
100 x 200mm 4 x 8”
615mm 24-1/4”
520mm 20-1/2”
310mm 12-1/4”
97 dB(A) K=3 dB(A)
110 dB(A) K=3 dB(A)
ah= 0.4 m/s
2
K=1.5 m/s
2
230V: 093-0001 110V: 093-0002
093-0003
093-0004
28mm 11/8” MAGNETIC DRILL 50mm 2” MAGNETIC DRILL 75mm 3” MAGNETIC DRILL
MAG
28
MAG
50
MAG
75

Evolution EVOMAG 28 Specifications

General

Brand	Evolution
Model	EVOMAG 28
Category	Drill
Language	English
